A Unidirectional Seal Knife Gate Valve is a type of valve commonly used in industrial applications where there is a need to control the flow of slurries, thick liquids, and other challenging fluids.
Product Description
A Unidirectional Seal Knife Gate Valve is a type of valve commonly used in industrial applications where there is a need to control the flow of slurries, thick liquids, and other challenging fluids. The valve is designed to handle tough materials that may include particles, fibers, or sludges that could clog traditional valves. The unidirectional seal feature means that the valve is specifically designed to operate effectively in only one direction of flow, providing a tight seal under that specific operating condition.
|
Size |
Design pressure |
|
DN50-DN100 |
PN16 |
|
DN125-DN200 |
PN10 |
|
DN250-DN400 |
PN7 |
|
DN450-DN600 |
PN5 |
|
DN650-DN750 |
PN4 |
|
DN800-DN900 |
PN3 |
|
DN1000 |
PN2 |
|
DN1100-DN1400 |
PN1 |
| Design Standard | MSS SP-81 |
| Flange Standard | DIN PN10, PN16, 150LB , JIS 10K etc... |
| Testing Standard | API598 |
| Operation | Manual, Electric, Pneumatic, hydraulic, Gear, Lever etc... |
| Main Material | GGG40, CF8, CF8M, WCB, Duplex steel etc... |
| Sealing Material | NBR, EPDM, PTFE, FKM, Graphite, Metal to Metal |
| Applicable Medium | Slurry and Wastewater Treatment, Pulp and Paper Industry, Mining, Chemical Processing, Oil & Gas; |
| Face to Face | MSS SP-81 |
| Leakage Class | ANSI/FCI 70-2 Class VI (Zero Leakage) |
| Gate Type | Knife Gate (sharp-edged, cutting through slurries/solids) |
| Pressure Rating | ANSI Class 150, 300, 600, PN10, PN16, PN25 |
1. Effective for Slurries;
2. Reliable Sealing;
3. Durable;
4. Low Maintenance;
5. Compact Design;
